25mm Cap Automatic Pillar Drilling Machine
40000-45000 INR/Piece
Product Details:
- Table Size 345 X 345mm Dia.
- Condition New
- Spindle Speed 73 to 1800 RPM
- Product Type Cap Automatic Pillar Drilling Machine
- Material Mild Steel
- Automatic Grade Automatic
- Power 1 Horsepower (HP)
- Click to View more
X
Price And Quantity
- 1 Piece
- 40000-45000 INR/Piece
Product Specifications
- 1 Horsepower (HP)
- 73 to 1800 RPM
- Electric
- Automatic
- New
- Mild Steel
- Cap Automatic Pillar Drilling Machine
- 345 X 345mm Dia.
- Green
Trade Information
- 10 Piece Per Week
- 1 Week
- GUNNY PACKING OR WOODEN CASE
- Asia, Australia, North America, South America, Eastern Europe, Western Europe, Middle East, Africa, Central America
- All India
- ISO 9001 : 2015,NSIC,CE CERTIFICATE
Product Description
25mm Cap Automatic Pillar Drilling MachineTechnical Specification :
| Model No. | SEW / S-25 |
| Drilling Cap. (in steel) | 25 mm |
| Column Dia. | 87.60 mm |
| Centre of Spindle to table | 255 mm |
| Max, Spindle to table | 650 mm |
| Max, Spindle to base | 1050 mm |
| Taper in spindle | M.T.3 |
| Spindle Travel | 185 mm |
| No. of speed | 8 |
| Range of Speed | 73 to 1800 RPM |
| Table size | 345 X 345mm Dia. |
| Base size (machined area) | 350 X 325 mm |
| Overall base size | 625 X 420 mm |
| Overall height with guard | 1675 mm |
| V-Belt selection | B-52 |
| Elec. Motor-1440 RPm | 1 H.P. |
| Wooden Case Size | 950 X 500 X 1525 mm |
