25mm cap Universal Radial Drilling Machine

Model No.

SEW / S-25

Drilling Cap. (in steel)

25 mm

Column Dia.

87.60 mm

Centre of Spindle to table

255 mm

Max, Spindle to table

650 mm

Max, Spindle to base

1050 mm

Taper in spindle

M.T.3

Spindle Travel

185 mm

No. of speed

8

Range of Speed

73 to 1800 RPM

Table size

345 X 345mm Dia.

Base size (machined area)

350 X 325 mm

Overall base size

625 X 420 mm

Overall height with guard

1675 mm

V-Belt selection

B-52

Elec. Motor-1440 RPm

1 H.P.

Wooden Case Size

950 X 500 X 1525 mm
